This electric self-propelled line marking machine makes line marking work effortless and efficient, tackling uphill construction with ease. Its chassis equipped with a differential ensures agile turning. The machine can be upgraded with an electric mixing device,Portable lithium batteries can be removed for charging.making it highly recommended.
| Drive method | 550W Electric motor |
| Battery | 48VDC/12Ah portable lithium battery, 8-hour runtime |
| Travel speed | Forward 10km/h, reverse 6km/h,gradeability 15° |
| Chassis | Dual-wheel differential, dual drum brakes |
Paint bucket capacity | 100kg |
Glass bead tank capacity | 15kg |
| Glass bead spreader | Adjustable spreading width and density |
Stove fuel | LPG |
Optional line width | 5,10,15,20,30,40,45cm |
Ground blade | Alloy-embedded ground blade |
Wheels | Metal hubs with heat-resistant rubber tires The rear wheel equipped with straight-line positioning device |
Dimension(LWH) | 1250 × 900 × 1000 mm |
Net weight | 140 kg |
