Marking setting, mixing ratio and stirring speed are configured via the control panel. The pneumatic extrusion mechanism ensures rapid and aesthetically pleasing formation of dot markings. The hydraulic self-propelled system facilitates more convenient and efficient construction operations.
Gasoline engine | Honda GX270(9HP) |
Drive method | Hydraulic motor with continuously variable transmission (CVT) |
Travel speed | Forward 10km/h, reverse 6km/h, gradeability 15° |
Mixing ratio | 98:2 |
Air compressor | 0.6m³/min |
Paint bucket capacity | 133L |
Glass bead tank | 20L pressurized tank |
Hardener tank capacity | 6L |
Cleaning agent tank capacity | 12.5L |
Optional line width | 15,20,30cm |
Dimension(LWH) | 1800 × 1400 × 1350 mm |
Net weight | 370 kg |
